Panasonic CQ-VX505MD
UNIT IS SOLD FIND ANOTHER IN THE SHOP →インテグレーテッド CD・MD・DSPレシーバー — The Panasonic CQ-VX505MD is an integrated CD/MD/DSP receiver from the same VX family as the CQ-VX3200D, but built around a 6-channel DSP output (2 inputs, 6 outputs) rather than a standard 4-channel layout — meaning front, rear, and a dedicated subwoofer channel can all be processed separately. The same 7-mode sound field selection (Live House, Concert Hall, Jazz Club, Stadium, Disco, Vocal, Cinema) and 7-band EQ carry over, paired with a 40W×4 + 10W max output stage. No cassette deck on this one — it's a clean CD/MD-only setup, which keeps things simple if tape was never your thing.
Bluetooth has been added, and tested.
Amplifier has been tested successfully.
CD has been tested successfully.
MD has not been tested.
Harness Included.
| CQ-VX505MD — KEY FEATURES | |
|---|---|
| Media | CD / CD-R/RW + MiniDisc — integrated CD/MD/DSP receiver (no cassette) |
| Tuner | FM/AM — FM 76.0–89.9 MHz (Japan domestic band), AM 522–1,629 kHz (9 kHz steps) |
| Power | 40W × 4 + 10W max output / 16W × 4 continuous (4 Ω, 1 kHz, 1% THD) |
| DSP / Sound | 6-channel DSP output (2-in/6-out) — 7-mode sound field (Live House, Concert Hall, Jazz Club, Stadium, Disco, Vocal, Cinema), 7-band EQ (80 Hz–10 kHz, ±12 dB) |
| CD/MD spec | Frequency response 5 Hz–20 kHz, S/N 90 dB (IHF-A), wow & flutter below measurable limits — both CD and MD sections |
| Pre-out | 600mV output level, 600 Ω impedance |
| Form factor | Double DIN (2-DIN) — 178 × 100 × 160 mm / approx. 2.7 kg |
