Kenwood DPX-5200M
MDコンポデッキ — The DPX-5020M is Kenwood's double-DIN MD/CD flagship — two optical formats, one unit, tuned for the Japanese domestic market. The MD section hits 0.005% THD and 90dB S/N. The CD section hits 0.01% THD and 93dB S/N. Both 1-bit D/A, both 8× oversampling, both tested and running clean. Mate, if you have no bloody idea what that means, it means its a damn good unit. If you're building a proper period-correct JDM interior, this is the deck.
Bluetooth is included, and tested.
Amplifier has been tested successfully.
MD has been tested successfully.
CD has been tested successfully.
Harness Included.
| DPX-5020M — KEY FEATURES | |
|---|---|
| Media | MiniDisc · CD |
| Tuner | FM 76.0–90.0 MHz · AM 522–1629 kHz — JDM tuner range |
| Power | 47W × 4 max · 29W × 4 rated (4Ω, 1kHz, 10% THD) |
| MD spec | 1-bit D/A · 8× oversampling · THD 0.005% · S/N 90 dB · Dynamic range 90 dB · 20 Hz–20 kHz |
| CD spec | 1-bit D/A · 8× oversampling · THD 0.01% · S/N 93 dB · Dynamic range 93 dB · 10 Hz–20 kHz |
| Pre-out | 1.5V / 10kΩ · Output impedance ≤600Ω |
| Form factor | Double DIN — 178 × 100 × 155 mm / 2.3 kg |
A note on this item
This is a vintage head unit. Every deck is tested by us before listing, but as a used product we're unable to offer a warranty. If it arrives damaged in transit and has developed a fault we are here to help ASAP, please get in touch — we'll do everything we can to sort it out for you. We just ask that you please be mindful of the product's age. Harness is not included unless otherwise specified in the listing.
