| Media |
CD and CD-R with MP3 decoding, plus MiniDisc. AV and TEL-LINK control on board |
| Tuner |
FM/AM. FM 76.0–90.0 MHz (Japan domestic band), AM 522–1,629 kHz. FM usable sensitivity 9 dBf, 50 dB quieting 15 dBf, S/N 70 dB, response 30 Hz–15 kHz (plus or minus 3 dB), separation 35 dB (1 kHz), THD 0.3% in stereo. AM sensitivity 28 dBu, S/N 50 dB |
| Power |
50W x 4 max output (JEITA), 18W x 4 rated (20 Hz–20 kHz, 1%, 4 ohm), 4 to 8 ohm speakers. Line out 4V measured from CD at 1 kHz |
| Conversion |
20-bit A/D at 64 times oversampling delta-sigma, 24-bit D/A at 128 times oversampling with an advanced multi-bit delta-sigma stage |
| Sound, STD mode |
Digital sound field with five factory settings, plus a 7-band graphic EQ offering six factory curves and six user curves |
| Sound, PRO mode |
V.S.E with six factory and six user settings, plus a parametric EQ with six factory and six user settings |
| CD spec |
Frequency response 5 Hz–20 kHz (plus or minus 1 dB), S/N 100 dB, dynamic range 92 dB, THD 0.015% |
| MD spec |
Frequency response 20 Hz–20 kHz (plus or minus 2 dB), S/N 100 dB, dynamic range 92 dB, THD 0.015% |
| MP3 support |
MPEG-1 Audio Layer-3, sampling 44.1 and 48 kHz, bit rates 32–320 kbps at 44.1 kHz and 32–256 kbps at 48 kHz including VBR. CD-ROM mode 1 and mode 2 form 1 with automatic detection, ISO9660 level 1 and 2, eight folder levels, up to 255 folders and files combined with a maximum of 150 folders, 16 characters shown for folder and file names |
| Expansion |
CeNET wiring for external changers, AUX input, AV and TEL-LINK control |
| Remote support |
Supports a wireless remote, so you can even add one to control it from across the cabin |
| Electrical |
DC 14.4V negative earth, 3.0A at 1W output, 15A fuse |
| Form factor |
Double DIN (2-DIN), 178 x 100 x 185 mm with a 159 mm mounting depth, approx. 3.1 kg |
